Nickel-based alloys, with nickel as the matrix (typically nickel content ≥ 50%) and alloying elements such as chromium, cobalt, molybdenum, tungsten, titanium, and aluminum added, are high-performance materials featuring excellent high-temperature resistance, corrosion resistance, fatigue resistance, and toughness. Widely applied in high-end fields including aerospace, petrochemical, nuclear energy, and marine engineering, their production process demands strict control over purity, composition uniformity, and microstructure regulation. The core process consists of seven key stages: Raw Material Preparation, Melting & Refining, Solidification Forming, Hot Working, Heat Treatment, Precision Machining & Surface Treatment, and Quality Inspection.
Base material: High-purity electrolytic nickel (Ni ≥ 99.95%) is adopted to avoid the introduction of harmful impurities such as iron, sulfur, and phosphorus.
Alloying elements: High-purity metal elements (e.g., chromium blocks, cobalt plates, molybdenum powder) or master alloys (e.g., Ni-Cr, Ni-Ti, Ni-Al) are selected to ensure element activity and composition stability, reducing burning loss and oxidation during melting.
Based on the chemical composition requirements of target alloy grades (e.g., Inconel 625, Hastelloy C-276, GH4169), batching calculation is performed using high-precision electronic scales (error ≤ 0.01%).
Considering the burning loss rate (usually 3%-8%) of volatile elements (e.g., titanium, aluminum) during melting, appropriate excess addition is conducted to ensure the final product composition meets international standards such as ASTM and AMS.
Due to the complex composition and high reactivity of nickel-based alloys, conventional melting is prone to oxidative inclusions, gas residues (oxygen, hydrogen, nitrogen), and composition segregation. Therefore, a combined process of "multi-step melting + vacuum refining" is required to ensure alloy purity and uniformity.
Principle: Electromagnetic induction heating is used to melt the batched materials in a vacuum environment (vacuum degree ≤ 10⁻³Pa), and electromagnetic stirring promotes uniform diffusion of alloying elements.
Core Functions:
Gas removal: The solubility of gases such as hydrogen and nitrogen in molten metal is significantly reduced in a vacuum environment, enabling effective degassing (final oxygen content ≤ 50ppm).
Preliminary alloying: Achieves uniform mixing of elements to avoid local composition segregation.
Removal of oxidizable impurities: The vacuum environment inhibits the oxidation of alloying elements, and slag formers (e.g., CaO-Al₂O₃) adsorb non-metallic inclusions (e.g., oxides, sulfides).
Application: Serves as the "master alloy melting" stage for nickel-based alloys, providing compositionally uniform crude ingots for subsequent refining.
Principle: Using the electrode rod prepared by VIM as the cathode and a water-cooled copper crucible as the anode, an arc (VAR) or electron beam (EBM) is generated in a vacuum environment to gradually remelt the electrode rod into an ingot.
Core Functions:
Further purification: During remelting, gases and low-melting-point impurities (e.g., lead, bismuth) are volatilized and removed, and inclusions settle under gravity or are adsorbed by the crucible wall, significantly improving alloy purity (oxygen content ≤ 20ppm).
Ingot quality improvement: By controlling the remelting rate (usually 5-15kg/min) and cooling intensity, ingots with fine grains and dense structure are obtained, eliminating defects such as central porosity and shrinkage cavities.
Differentiated Selection:
VAR: Relatively low cost, suitable for mass production of conventional nickel-based alloys (e.g., GH4169).
EBM: Higher heating temperature (up to 3000℃) and better degassing effect, suitable for the preparation of high-end aerospace nickel-based alloys (e.g., single-crystal turbine blade alloys).
For alloys used in ultra-high-temperature and strong-corrosion environments (e.g., alloys for nuclear reactor pressure vessels), an ESR process can be added after VAR/EBM. The resistance heat of the electroslag melts the electrode, and the slag pool plays roles in refining, purification, and protection, ultimately obtaining high-quality ingots with a smooth surface and no internal defects, further improving the uniformity of mechanical properties.
According to the final product form (ingot, plate, pipe, forging), an appropriate solidification forming process is selected, with the core goal of regulating the grain structure and avoiding composition segregation.
Sand casting or investment casting is adopted to inject the refined alloy liquid into the mold for natural cooling and solidification. The cooling rate (5-20℃/min) needs to be controlled to avoid thermal stress cracking caused by rapid cooling.
For core components such as aerospace engine turbine blades and guide vanes, directional solidification technology is adopted:
Principle: By controlling the cooling direction of the mold, the alloy liquid solidifies in a single direction to form a columnar grain structure, eliminating transverse grain boundaries and improving high-temperature strength and creep resistance.
Single-crystal solidification technology: On the basis of directional solidification, a single grain is selected for growth through a "selector", ultimately obtaining a grain-boundary-free single-crystal alloy with extreme high-temperature resistance (capable of long-term operation above 1100℃).
The refined alloy liquid is atomized into fine droplets (diameter 50-200μm) through an atomizing nozzle, sprayed onto a water-cooled substrate at high speed, and rapidly solidified (cooling rate 10³-10⁵℃/s). Advantages: Avoids macrosegregation, refines grains to the micron level, simultaneously improves alloy strength and toughness, and can directly prepare near-net-shape blanks (e.g., plates, bars), reducing subsequent processing volume.
Nickel-based alloys have high hardness and poor plasticity at room temperature, requiring hot working to refine grains, eliminate casting defects, and improve mechanical properties.
Heating temperature: Controlled at 950-1200℃ according to the alloy type (e.g., 1050-1150℃ for Inconel 625), and holding for 2-4 hours to ensure full softening of the alloy.
Processing method: Open die forging, closed die forging, or isothermal forging is adopted to break coarse grains in the cast structure through high-pressure deformation (deformation 30%-70), forming a dense fibrous structure.
Key control: Avoid grain growth caused by excessively high processing temperature or cracking caused by excessively low temperature; real-time monitoring of blank temperature and deformation rate is required.
Rolling: The forged blank is rolled into plates or strips in a hot state, and the rolling temperature (900-1100℃) and reduction (5%-15% per pass) are controlled to ensure uniform thickness and smooth surface of the plates.
Extrusion: For pipes and bars, the hot blank is placed in an extruder and extruded into shape through a die, improving the density and mechanical property isotropy of the alloy.
Heat treatment is the core stage for realizing "performance customization" of nickel-based alloys. By controlling the heating, holding, and cooling processes, the microphase composition (e.g., γ' phase, carbide phase) of the alloy is adjusted, thereby optimizing properties such as strength, toughness, and corrosion resistance.
Process parameters: Heating temperature 1050-1200℃, holding time 1-4 hours, rapid water cooling or air cooling.
Core purpose: Fully dissolve the strengthening phases (e.g., γ' phase, carbides) in the alloy into the austenitic matrix, eliminate internal stress after hot working, and obtain a uniform supersaturated solid solution.
Process parameters: Heating temperature 700-900℃, holding time 4-24 hours, furnace cooling or air cooling.
Core purpose: Enable alloying elements (e.g., titanium, aluminum, molybdenum) in the supersaturated solid solution to precipitate in the form of γ' phase (Ni₃(Ti,Al)), carbides (e.g., MC, M₂₃C₆), forming弥散ly distributed strengthening phases, which significantly improve the high-temperature strength and hardness of the alloy.
Process parameters: Heating temperature 850-950℃, holding time 2-6 hours, air cooling.
Core purpose: Promote the precipitation of carbides (e.g., NbC), avoid intergranular corrosion caused by carbide precipitation during subsequent high-temperature service, and improve the corrosion resistance stability of the alloy.
According to product requirements, machining methods such as turning, milling, and grinding are adopted to process the hot-worked blank to the final dimensional accuracy (tolerance ≤ ±0.01mm). Nickel-based alloys have obvious work hardening, so cemented carbide or diamond tools are selected, and the cutting speed and feed rate are controlled to avoid tool wear.
Pickling and passivation: A mixed solution of nitric acid and hydrofluoric acid is used to remove surface oxide scale and form a dense passivation film to improve corrosion resistance.
Polishing: For high-precision components (e.g., aerospace parts), mechanical polishing or electrochemical polishing is performed to make the surface roughness Ra ≤ 0.8μm.
Coating treatment (optional): For components serving in extreme environments, plasma spraying or vapor deposition technology is used to prepare wear-resistant/corrosion-resistant coatings (e.g., Al₂O₃, TiN).
Nickel-based alloys are mostly used in key equipment, so quality inspection runs through the entire production process. The core inspection items include:
Direct-reading spectrometers and ICP-MS (Inductively Coupled Plasma Mass Spectrometry) are used to detect chemical composition to ensure compliance with grade standards. Precise quantitative analysis of key elements (e.g., titanium, aluminum, molybdenum) is conducted with an error ≤ 0.05%.
Metallographic microscopes and scanning electron microscopes (SEM) are used to observe grain size, phase composition, and inclusion distribution. For single-crystal/directionally solidified alloys, electron backscatter diffraction (EBSD) is used to detect grain orientation to ensure compliance with design requirements.
Room/high-temperature tensile test: Tests tensile strength, yield strength, and elongation (high-temperature test temperature up to 1000℃).
Impact test (Charpy V-notch): Evaluates the toughness of the alloy.
Creep test: Simulates the high-temperature service environment to test the deformation resistance of the alloy under long-term load.
Ultrasonic Testing (UT): Detects internal defects such as porosity, shrinkage cavities, and cracks.
Penetrant Testing (PT)/Magnetic Particle Testing (MT): Detects surface and near-surface cracks.
Eddy Current Testing (ET): For pipes and plates, detects surface defects and thickness uniformity.
Process Stage | Core Advantages | Typical Application Scenarios |
Vacuum Melting + Remelting | High purity (oxygen content ≤ 20ppm), uniform composition | Aerospace, nuclear energy alloys |
Directional/Single-Crystal Solidification | Excellent high-temperature creep resistance | Turbine blades, guide vanes |
Hot Working + Aging Treatment | Balanced high strength and toughness | Petrochemical high-pressure vessels, marine engineering structural parts |
Spray Forming | Grain refinement, no segregation | High-performance plates, bars |
The core of the nickel-based alloy production process lies in "precision control" — every step from raw material batching to final inspection must strictly follow process parameters to ensure stable service in extreme environments. For process optimization schemes targeting specific grades (e.g., Inconel 718, Hastelloy B-2) or application scenarios (e.g., deep-sea corrosion protection, aerospace engines), further details can be provided for customized explanation.
